Operating Band

Cat M1:
 LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/
 B85

 Cat NB2:(*Cat NB1 is available in Brazil)
 LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85

Data Transmission

eMTC (DL) 588 Kbps
 eMTC (UL) 1119 Kbps
 NB2 (DL) 127 Kbps
 NB2 (UL) 158.5 Kbps
 NB1 (DL) 32 Kbps
 NB1 (UL) 70 Kbps

Frequency

EGPRS 850 / 900 / 1800 / 1900 MHz

Data Transmission

GPRS: (DL) 107 Kbps, (UL) 85.6 Kbps
 EDGE: (DL) 296 Kbps, (UL) 236.8 Kbps

GNSS Type

u-blox All-in-One GNSS receiver

Sensitivity

Autonomous: -147 dBm
 Hot start: -156 dBm
 Reacquisition: -160 dBm
 Tracking: -162 dBm

Position Accuracy (CEP)

Autonomous: < 2.5m

TTFF (Open Sky)

Cold start: 27s average
 Warm start: 27s average
 Hot start: 1s average

Dimensions

87 × 51 × 30mm
 3.43’’(L) × 2.01’’(W) × 1.18’’(H)
 87 × 51 × 33.5mm
 3.43’’(L) × 2.01’’(W) × 1.32’’(H) (magnetic case mounting version)

Weight

140g (4.94oz)
 160g (5.64oz)
 (magnetic case mounting version)

Backup Battery

3 CR123A lithium batteries, 1400 mAh

Standby Time

Standby current: < 8 µA
 1 report per day (GNSS on): 5 years
 1 report per day (cell ID only): 7 years
 *The standby time is estimated under the condition of operating with LTE CAT M1/NB-IoT and the CSQ is greater than 15, working at a constant ambient temperature of 25°C and reporting once a day without any sensors.

Waterproof

IP67 compliant

Operating Temperature

-20℃ ~ +60℃

Internal Temperature Sensor

For temperature monitoring
 Accuracy: ±1℃

Internal Light Sensor

For tamper detection

Internal Motor

For vibration feedback after successful operation of function button

Magnetic Mounting Case (Optional)

For easy installation on metal surface

Buffer Messages

Up to 10,000 buffer messages

BLE*

Support BLE 5.0

Command Set

@Track protocol command

Transmit Protocol

TCP, UDP, SMS

Working Modes

Power saving mode for long standby time
 Continuous mode for emergency tracking

Scheduled Timing Report

Report position and status at preset time intervals

Geo-fences

Support up to 20 internal geo-fence regions

Low Power Alarm

Alarm when internal battery is low

Wakeup Report

Report when the device wakes up

Motion Detection

Motion detection based on internal 3-axis accelerometer

Reporting Frequency Adjustment

Intelligent adjustment of reporting frequency

Function Button

Used for power on/off and working status checking

BLE Antenna*

Internal only*

LTE Antenna

Internal only

GNSS Antenna

Internal only

LED Indicators

GNSS,Status
