LTE Specifications:
Operating Band | Cat M1: LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85 |
Cat NB2: LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85 |
EGPRS Specifications:
Frequency | EFPRS: 850/900/1800/1900 MHz |
GNSS Specifications:
GNSS Type | All-in-one multi-constellation GNSS Receiver |
Constellation Support | GPS, BEIDOU, GLONASS, GALILEO, AGPS |
Position Accuracy (m@CEP50) | Autonomous: < 2.5m |
General Specifications:
Dimensions | 212(L) × 86(W) × 30(H) mm 8.35(L) × 3.39(W) × 1.18(H) inch |
Weight | 572g (20.2oz) |
Internal Battery | 6 x ICR18500 lithium batteries, 3.7V,12000mAh |
Standby Time | Continuous Mode: 1 report/minute (2 Working hours per day): 80 days |
Sleeping Mode: 1 report/hour: 5 months 1 report/day: 5 years 1 report/day (need to be solar charged regularly): 10 years | |
Waterproof | IP67 |
Operating Temperature | -20 °C~+70 °C (-4 °F~+158 °F) |
Mounting | Screw / Magnet Mounting Additional secure steel cable |
Region | Global |
Certificate | FCC (Planning) PTCRB (Planning) |
Interfaces:
Charging Port | 4-pin magnetic connector for charging and configure / FW upgrade |
Cellular Antenna | Internal only |
GNSS Antenna | Internal only |
BLE Antenna | Internal only |
Wi-Fi Antenna | Internal only |
LED Indicators | GNSS, CEL, PWR |
Air Interface Protocol:
Transmit Protocol | TCP, UDP, SMS |
Scheduled Timing Report | Report messages at preset time intervals |
Geo-fences | Automatically reports when entering / exiting Geo-Fence |
Low Power Alarm | Alarm when internal battery is low |
Battery Health | Report battery condition (%) / status |
Temperature Monitoring | Report environment temperature at preset time intervals |
Tamper Detection | Alarm when device is removed |
OTA Control | Remote configure parameters to change position interval, measurement interval, active/ deactivate sensor, upgrade FW |
